Gaussian Noise Model on Dispersion-Unmanaged Submarine Links
Skip to main content
MapYourTech | InDepth Series

Gaussian Noise Model on Dispersion-Unmanaged Submarine Links

Why the WDM signal reaches Gaussian statistics once chromatic dispersion has decorrelated the channel phases, how the model supports the GSNR metric on open cables, and the low-dispersion and low-baud conditions where it stops holding.

Coherent Transmission

Compensation happens in the electrical domain; the physics happened in the fiber.

What You Will Learn

  • Define nonlinear interference power spectral density from first principles and convert it to an SNR in one line of arithmetic (Section 2).
  • Quantify phase decorrelation as symbol overlap: 47 symbols after one 60 km span, 95 after two, 8,546 across the full 10,800 km reference link (Section 4).
  • Build the GN closed-form NLI estimate for reference link S1 and read each of its four terms against a physical mechanism (Table 4, Section 6.1).
  • Aggregate SNRASE 12.62 dB, SNRNLI 20.63 dB and SNRGAWBS 21.23 dB into a GSNR of 11.50 dB, then apply the generalized droop correction to reach 11.44 dB (Section 6.3).
  • Locate the nonlinear threshold from the condition that NLI variance equals half the ASE variance, and price the 0.46 dB of GSNR that separates it from the SDM operating point (Section 8.2).
  • Run the inverse back-to-back measurement that turns a modem Q-factor into a transponder-independent GSNR, and state its measurement conditions (Section 7.2).
  • Convert a measured GSNR into a capacity bound: 11.44 dB over 4.5 THz gives 32.5 Tb/s per fiber pair before implementation gap (Section 9.1).
  • Apply the two validity boundaries quantitatively: dispersion below 4 ps/(nm·km) and symbol rates near 10 GBd, using the 1,295 ps/nm overlap criterion (Section 11).

1. Introduction

A 69.4 GBd carrier launched into a transpacific cable at −0.78 dBm arrives 10,800 km later carrying three noise terms that a coherent receiver cannot tell apart. Amplified spontaneous emission (ASE) from 180 erbium-doped fibre amplifiers (EDFAs) contributes 77.2% of the received noise variance, nonlinear interference (NLI) generated by the Kerr effect contributes 12.2%, and guided acoustic-wave Brillouin scattering (GAWBS) contributes the remaining 10.6% (GN-model result on reference link S1, derived in Section 8). The receiver's digital signal processing (DSP) sees one Gaussian noise floor and reports one signal-to-noise ratio. That indifference is not a limitation of the instrument. It is a property of the channel, and the whole commercial architecture of the open cable rests on it.

The property has a physical cause with a measurable onset. Chromatic dispersion in a fibre with no inline compensation spreads every symbol across its neighbours and randomises the relative phases of the wavelength-division multiplexing (WDM) comb. On reference link S1 a symbol overlaps 47 neighbours after one 60 km span, 95 after two, and 8,546 by the time it reaches the far shore (derived from the accumulated dispersion, Section 4.2). Once several tens of independent contributions add at each instant, the central limit theorem applies to the resulting distortion and the Kerr-generated field takes circular Gaussian statistics. The distortion then has no structure the DSP can exploit, and its variance becomes the only quantity that matters.

The Gaussian Noise (GN) model turns that observation into a closed-form estimate of the variance. It treats the transmitted WDM signal as a stationary Gaussian process, computes the power spectral density of the four-wave mixing products that fall inside the carrier of interest, and accumulates them span by span. What comes out is a nonlinear signal-to-noise ratio, SNRNLI, that composes with the amplifier noise term by the reciprocal sum rule. The composed quantity is the generalized signal-to-noise ratio (GSNR), and ITU-T G.977.1 defines it for exactly this purpose: a figure that describes the cable and nothing else, measurable before any transponder is bought (standard-specified).

Submarine links sit further inside the model's validity region than any other system class. Span lengths of 50 to 80 km, local dispersion above 20 ps/(nm·km) on pure silica core fibre (PSCF), amplifier counts in the hundreds, and no dispersion compensation modules anywhere in the wet plant combine to produce the strongest decorrelation in commercial optical transmission. That is why GSNR became a contractual parameter on subsea cables years before terrestrial planning tools adopted the same arithmetic, and why an open cable can be accepted, sold in spectrum blocks, and upgraded by a third-party terminal vendor on the strength of one measured number per frequency.

1.1 Scope and Boundary Conditions

This article covers the Gaussian description of nonlinear interference on repeatered, dispersion-unmanaged submarine cable systems: the physical condition that produces Gaussian statistics, the closed-form GN estimate of NLI variance, the aggregation of ASE, NLI and GAWBS into GSNR under both the additive and generalized droop rules, the measurement procedure that recovers GSNR from a modem Q-factor, and the two conditions under which the description degrades. Enhanced GN (EGN) and time-domain variants appear where they change a design decision, not as a derivation. Unrepeatered systems, dispersion-managed legacy cables and multicore crosstalk are named where they bound the argument and are otherwise outside the scope. The companion treatment of the model in its terrestrial form is available in the Gaussian Noise model reference, and the relationship between the modelled quantity and the instrument reading is set out in GOSNR versus OSNR.

1.2 Reference Link S1

Every calculation in this article uses one link, so a capacity quoted in Section 9 traces back to a launch power in Section 6. Reference link S1 is a transpacific-class open cable of the kind built since the middle of the last decade: PSCF throughout, C-band only, EDFA repeaters on 60 km spacing, and a fibre pair count high enough that each pair is operated below its own nonlinear threshold.

Table 1: Reference link S1 parameters
ParameterValueEvidence class
Span length60 kmdesign assumption
Span count180design assumption
System length10,800 kmderived
Fibre typePSCF, ITU-T G.654-classstandard-specified
Effective area150 µm²typical deployed value
Cabled attenuation0.160 dB/kmtypical deployed value
Dispersion coefficient at 1550 nm20.5 ps/(nm·km)typical deployed value
Nonlinear coefficient0.60 W⁻¹km⁻¹derived
Span loss9.6 dBderived
Repeater noise figure5.0 dBtypical deployed value
Repeater total output power17.0 dBmdesign assumption
Carrier count and spacing60 on a 75 GHz griddesign assumption
Occupied bandwidth4.5 THzderived
Symbol rate per carrier69.4 GBddesign assumption
Per-carrier launch power−0.78 dBmderived
Accumulated dispersion221,400 ps/nmderived
GSNR at the operating point11.44 dBGN-model result

The nonlinear coefficient follows from the effective area alone. With γ = 2πn₂/(λAeff), an effective nonlinear index of 2.22 × 10⁻²⁰ m²/W at 1550 nm and a 150 µm² effective area give 0.60 W⁻¹km⁻¹, roughly half the 1.3 W⁻¹km⁻¹ of terrestrial ITU-T G.652.D fibre (derived). Halving γ divides the NLI power spectral density by four at fixed launch power, which is the first-order reason large-effective-area fibre reaches the sea floor and small-effective-area fibre does not. Fibre selection and its effect on the nonlinear budget is developed further in the optical fibre parameter reference.

1.3 Three Statements That Organise the Argument

The Gaussian description holds because dispersion destroys the phase structure of the signal, not because the Kerr effect is weak; the strongest nonlinear regimes on S1 are also the most Gaussian. The GSNR that follows describes the cable independently of the transponder, which is what makes an acceptance contract possible without a transponder. And the description degrades along two axes only, local dispersion and symbol rate, both of which enter through the same overlap criterion, which is why one number in picoseconds per nanometre bounds the whole validity region. Sections 4, 7 and 11 develop the three in turn.

Takeaway: On a dispersion-unmanaged submarine link the receiver measures one Gaussian noise floor built from ASE, NLI and GAWBS in roughly a 77:12:11 variance ratio, and the GN model exists to predict the middle term from cable parameters alone.
